Technical Solution

SoC Solution
SoC Solution
RTL Design, Platform Design & Verification, FPGA Verification 부터
Design Service 분야의 DFT Insertion, Layout, PKG / Test까지
시스템반도체 개발 및 제작에 필요한 모든 솔루션을 제공합니다.

Design Service Flow

  • STEP 1

    Spec. Decision
    RTL Coding

  • STEP 2

    Synthesis

  • STEP 3

    Netlist
    Hand-off

  • STEP 4

    DFT

  • STEP 5

    Placement
    Routing

  • STEP 6

    Verification
    & PG

  • STEP 7

    Test Vector
    Generation

  • STEP 8

    Failure
    Analysis

Design Service Level

Level

Spec. Decision
RTL Coding

Synthesis

DFT

Placement
Routing

Verification
& PG

Test Vector
Generation

Failure
Analysis

Level 0

Spec. Hand-off
Level 1

RTL Hand-off
Level 2

Netlist Hand-off
Level 3

GDS Hand-off

Total Solution

  • FULL CHIP DESIGN

    ( SPEC / DESIGN )

    Design / Verification Platform

    System Architecture Analysis

    Power Management Control

    Real Emulation with FPGA

    IP Supplier Partnership

    Device Driver, BSP, OS porting

  • PHYSICAL
    IMPLEMENTATION

    ( SYNTHESIS / DFT )

    DFT (SCAN / BIST / JTAG)

    In-system Test

    STA (Static Timing Analysis)

    Synthesis & Timing Closure

  • PHYSICAL DESIGN

    ( AUTO P&R )

    Full Chip Floor Plan

    Hierarchical Physical Design

    Low Power Design

    SI Check
    (IR Drop, Crosstalk-Noise)

  • PKG & TEST Develop

    ( Assembly & TEST )

    Package Design

    Test vector generation

    ATE test set-up

    Qualification & Reliability

    Q.A & Failure analysis

  • Mass Production

    ( SCM )

    Wafer Business

    Full Turn-key Business
    (Wafer + PKG + TEST)

Advanced Technology

  • AI / HPC
    AI Accelerator, Datacenter, Server, Cloud Computing, Edge AI, XR/AR Processor
  • Automotive
    ADAS, Digital Cockpit, Network Processor, Vision Processor, Automotive MCU
  • Consumer
    High-End Appliances MCU, Printer SoC, Smart Home, Wearable AI Device, AIoT Application
  • Industrial
    Digital Security SoC, AI-Enhanced Surveillance ISP, Smart Mobility, Industrial Robot, Digital Twin
SoC Design

Vision & Mission

Vision & Mission
Vision & Mission
01

SoC Design Solution

Spec-to-Design

SoC System Design

SoC Verification

SoC FPGA protype

Reliable Design Process

02

SoC Design Platform

SoC System Platform

SoC Verification Platform

SoC FPGA Platform

ARM Partnership

IP Supplier Partnership

Early Start, Fast Optimize

03

High-Performance Design

NoC/Memory System Optimization

Maximize Clock Frequency

Hardening for Computing Clusters

Physical Design Consideration

04

Low-Power Design

Power Domain Scenario

Design for Dynamic clock-gating

05

Software Development

Device Driver, BSP Development

Linux/RTOS Porting

Firmware for FPGA Verification

System Bring-up

SoC Design Solution

  • 01

    SoC Design

    SoC/System Architecture

    Processing Core

    IP/xPU Hardening

    Full Chip TOP Integration

    PPA Optimization

  • 02

    SoC Verification

    IP/System Verification

    FPGA Prototyping

    Emulation for Architecture

    SoC TOP Verification

    Sub Platform Verification

  • 03

    Software Solution

    SoC Architecture Software Stack

    BSP (Board Support Package) to SDK (S/W Development Kit) TF-A (Trusted F/W), OP-TEE (Trusted OS), U-Boot, RTOS (Zephyr), Linux (Device Driver/Tree), Buildroot

    System Solution Optimization

    Performance Optimization

SoC System Platform
ARM-based SoC System : Ready for Entry-to-Cutting Edge
3rd Party IP with Partnership
Early Start and Fast Optimization
SoC Verification Platform
Systematic Configured & Re-usable Environment
All Verification Cases from Top to Sub in One Environment
Configurable Alternative Models for Integrated Units
Light and Reliable against Integration Issue
Easy Porting your System into One Verification Env.
SoC Design Solution
FPGA board with SoC System Platform
Fast Emulation for your IP on SoC System Platform
Fast Emulation for your System
Fast Iteration for your IP / System Architecture
High Performance

Physical
Implementation

Hardening for
Computing Clusters

CPU

GPU

NPU

Hash Core

Physical & Power-aware
Logic Synthesis

Logic Synthesis with physical information and power scenario

Placement-Aware Multi-Bit Register Banking

Physically aware Clock Gating restructuring

Design for Testability

Support advanced
DFT solutions

Low pin count test with serializer

Power Aware DFT

Test Fail Diagnosis

Memory BIST
(Built-In Self Test)

Memory BIST/BIRA for higher SRAM yield

Repair solution with eFuse & OTP

Logic BIST

hardware based in-field testing method

on-chip generated random patterns for safety and mission critical applications

In-system test

for safety-critical applications such as automotive, aerospace, and medicine

Use IST(In-System Test) controller through IJTAG network

to access the chip during operation

SCAN
(Advanced DFT Skill)

Scan test for improved test coverage for lower DPPM

Stuck-At, Bridge, Transition, Path-delay, OCCT, Burn-in

IDDQ Test

IDDQ test for additional fault coverage

Boundary Scan

Inter-chip connection test method for system level testing

Physical DFT consider

Physical Reordering and Repartitioning

Physical Design

Accurate and
robust timing analysis

LVF based variability library

Moment-based LVF to cope with non-Gaussian effect

Parametric OCV method

CCS/CCSN-based STA

Statistical Rvia STA

NP-Skewed corner STA for hold timing, min-pulse, and DCD check only

Physical optimization

BEOL-aware delay optimization (BEOL resistance increase impacting path delay)

Mixed DDB/MDB Flow

Physical-aware Timing ECO

Minimize physical side-effect for ECO

MIM-aware Timing ECO

Produce a single ECO file for Multiply Instantiated Module

Accelerate multi-core CPU/GPU timing closure

Low Power

  • 01

    Dynamic Power Optimization

    Multi-supply Voltage & Voltage Island

    In-Rush Current prevented power gating

    Clock/Memory-Gating

    Dynamic Voltage Frequency Scaling

    Vector-Driven Optimization

    Decap pre-placement method

    Merge or split ICG / Multi-bit flip-flop

    Low Power CTS (Concurrent Clock and
    Data Optimization)

  • 02

    Leakage Power Optimization

    Multi-Vth Optimization

    Gate-Length Biasing

    Sign-off Leakage Optimization

  • 03

    Low Power Verification

    Low power static rule check

    Power-aware Simulation

    Power-aware equivalence check

Power & Signal Integrity

  • 01

    Power Integrity Solution

    Power Plan based on Early Prototyping Analysis

    Dynamic Voltage Drop Analysis

    Static Power Analysis

    Power EM / BUMP Current

    P/G Resistance check

  • 02

    Signal Integrity Solution

    Signal EM

    Glitch Noise analysis

    Clock Jitter validation

    Duty-cycle distortion methodology

    Clock Propagation Check

    3-row decap inverter on CTS
